Adequate cutting performance even for the most demanding cuts
Detachable workpiece supports and extended table extensions for easy control of even long workpieces during cutting
Practical and versatile even for the most demanding cuts, thanks to the Double inclination function

Technical data
The most important data
Cutting capacity 0°
70 x 305 mm
45° oblique cutting capacity
70 x 215 mm
45° inclined cutting capacity
42 x 305 mm
Angle setting
48° Left / 48° Right
Inclined position
47° Left / 47° Right
Tool dimensions (width x length x height)
464 x 770 x 606 mm
Number of idle revolutions*
5,200 rpm
Saw blade diameter
216 mm
Blade hole Ø
30 mm
Weight*
16.8 kg
Nominal absorbed power
1,200 W
Voltage
220 – 240 V
Package dimensions (width x length x height)
464 x 770 x 606 mm
Noise/Vibration Information
Sound pressure level
95 dB(A)
Sound power level
109 dB(A)
Uncertainty of the K measurement
3 dB
