Omron 24V 15W 650mA DIN rail switching power supply The S8VK-G series includes a wide range of products with extremely compact dimensions, 13% smaller than similar power supplies. Furthermore, it is the smallest in the category. Wide operating temperature range (-40... +70 °C) Dual output terminals (three for negative) to allow for simple wiring High efficiency (90%) to reduce energy consumption Power boost functionality (120%) New clip for DIN rail mounting which guarantees high resistance to vibrations and allows for easy installation  Characteristics Brand: Omron Industrial Automation Supplier code: S8VK-G01524 EAN code: 4548583357662 Type: Single-phase power supply Power 15W Voltage 100 - 240 VAC Allowable range: 85 to 264 VAC, 90 to 350 VDC, 2 phases less than 240 VAC Output voltage 5V - 12V - 24V Output current 3A - 1.2A - 0.65A Dimensions(W × H × D) [mm] 22.5 × 90 × 90 Technical specifications Efficiency (typ. at 230 VAC) 80% (24V) Input Input voltage 100-240 VAC Voltage range 85 to 264 V AC, 90 to 350 V DC. 2 phases below 240 VAC Outputs Voltage adjustment range (with V.ADJ) -10% to 15% Influence of input variation 0.5% max. (at 85 to 264 VAC input, 100% load) Load variation Influence 3.0% max. (5V), 2.0% max. (12V), 1.5% max. (24, 48 V), at 0% to 100% load Influence of temperature variation 0.05%/°C max. Overload protection Yes, 130% of the rated current typ. Increased power 120% of the rated current Overvoltage protection Yes Operating ambient temperature −40 to 70°C (−40 to 158°F) Series operation Yes, up to 2 units Parallel operation Yes, up to 2 units EMI Complies with EN 61204-3, EN 55011 Class B EMS Complies with EN 61204-3 high severity levels Harmonic current emissions Complies with EN 61000-3-2 Approved standards UL: UL 508 (Listing), UL 60950-1, cUL: CSA C22.2 No. 107.1 and No. 60950-1, UL 1310 Class 2 output for 15 W, 30 W, 60 W EN/VDE: EN 50178 ( =VDE0160), EN 60950-1 (=VDE0805), Lloyd's Register ANSI/ISA 12.12.01 Standards met SELV (EN 60950-1/EN 50178/UL 60950-1), PELV(EN 60204-1,EN 50178), Safety of power transformers (EN 61558-2-16), EN 50274 for terminal parts Degree of protection IP20 EN/IEC 60529
