PIR MERGE JQ Kanlux motion sensor Kanlux MERGE JQ Is the motion sensor with a maximum motion detection range of 5 meters. Its horizontal operating angle is 360 degrees. It is possible to adjust both the lighting time and the external lighting level at which the sensor works. Background information EAN13: 5905339076908 Vendor code: 7960 Color: white Material: plastic material Place of use: inside Weight and dimensions Height [mm]: 83 Width [mm]: 55 Length [mm]: 83 Weight: 108g   Technical data Voltage nominal [V]: 220-240 AC Nominal frequency [Hz]: 50/60 Color: white Maximum power [VA]: 1200 IP degree 20 Mounting location: for flush mounting in the wall Degree of protection against electric shock: II Possibility of mounting on normally flammable surfaces: yes Sensor range [m]: max 9 Range of action of the sensor [ø]: H150 / V60 Minimum run time [s]: 10 Maximum running time [min]: 7 Sensor operating time [second-minute]: 10-7 Sensor type: PIR Setting the intensity of illumination with which the sensor detects motion [lx]: 3-2000 Micro-interval between relay contacts Operating temperature [°C]: 5÷25 Type of connection: terminal block Sections of cables used [mm]: 1÷2,5
