WiFi Smart 16A Relay w Temp & Humidity Sensor
€ 35.00
Description
Tuya Smart WiFi Temperature & Humidity Relay Switch – 16A 3000W with RF433 & Energy Monitoring
Enhance your smart home automation with the Tuya Smart WiFi Temperature & Humidity Relay Module. This intelligent switch is designed to monitor ambient conditions and automatically control connected devices based on temperature and humidity thresholds. Ideal for climate-sensitive environments, it offers real-time monitoring, energy tracking, and seamless scene integration.
Key Specifications
Input Voltage: AC 85–250V
Max Current: 16A
Max Load Power: 3000W
Enclosure Material: Fire-retardant ABS V0
Dimensions: 94 × 57 × 32 mm
Sensor Type: Temperature & Humidity
Probe Material: ABS
Temperature Range: -40°C to 80°C
Humidity Range: 0–99.9% RH
Sensor Operating Voltage: 3.0–5.5V
Protocols: WiFi + RF433
Features: Energy Consumption Monitoring, Scene Linking, Remote Control via Tuya/Smart Life App
Intelligent Ambient Monitoring & Auto Switching
The integrated temperature and humidity sensor allows the module to monitor environmental conditions in real time. When preset thresholds are met, the relay can automatically switch connected devices on or off. Use cases include:
Activating fans or dehumidifiers when humidity exceeds 70%
Powering heaters when temperature drops below 18°C
Turning off air conditioners once optimal climate is reached
Controlling grow lights or ventilation systems in greenhouses
Scene Automation & Multi-Device Linking
Compatible with the Tuya ecosystem, this module supports custom scenes that link multiple smart devices. Examples include:
“If temperature > 30°C, turn on ceiling fan and send notification”
“If humidity < 40%, activate humidifier and set RGB light strip to blue”
“Schedule relay to power on water pump at 6 AM and off at 6:30 AM”
“Combine with door sensor: if door opens and temp > 28°C, activate AC”
Scenes can be configured via the Tuya Smart or Smart Life app, offering intuitive control and remote access.
Energy Monitoring & RF433 Support
Monitor real-time energy consumption of connected appliances to optimize usage and reduce costs. The built-in RF433 receiver allows local control via compatible remotes, offering flexibility for manual override or offline operation.
Ideal Use Cases
Smart HVAC control
Server room temperature regulation
Greenhouse automation
Bathroom humidity management
Pet habitat climate control
Industrial equipment monitoring
Why Choose This Module?
Whether you're building a smart home, managing a commercial space, or optimizing energy usage, the Tuya Smart WiFi Relay with Temperature & Humidity Probe delivers precision, automation, and scalability in a compact, fire-retardant housing.
