Manufacturer HONGFA RELAY Relay type electromagnetic Contact configuration SPDT Rated coil voltage 24V DC Load capacity DC @R (with resistance load) 1A / 120VAC Load capacity DC @R (with resistance load) 1A / 30VDC Maximum current per contact 5A Commutative voltage max 240V AC, max 30V DC Relay version subminiaturized, of signal Editing PCB Coil resistance 2.8kÎ © Minimum coil tension 18V DC Max. coil tension 31.2V DC intervention time 10ms External dimensions 15.7 x 11 x 12mm release time 5ms Coil power absorption > td class = "span-10 col-md-8 last" style = "color: # 000000; font-family: Verdana, Arial, Helvetica, sans-serif; font-size: 10px; margin: 8px; cursor: text; border: 1px dashed #bbbbbb; "> 200mW Working temperature - 25 ... 70 ° C Contact resistance 100mÎ © Contact material AgNi Spacing of the derivations 2.54mm
